Roanwell Headsets

The Falcon

FAA TSO approved C57a Cat B and C58a Cat B

Headband and microphone/boom adjustable without tools

Boom rotates 320 degrees for comfortable and secure position on the left or right side

Dynamic M-87 microphone includes 3-way adjustment without tools

Microphone cord allows connection to an oxygen/chemical mask

Foam-filled headband with washable sock

Ear cushions available with foam or gel filling per customer’s specifications

Meets noise attenuation requirements of MILDTL-83511 and MIL-PRF-87819

Comes in Green, Black, or Grey

Active Noise Reduction (ANR) variant available

Categories:

Headsets

Tags:

Aerospace, Military, Popular

MORE ABOUT THIS PRODUCT

The Falcon is a rugged, double-sided headset that is ideal for high noise applications requiring comfort as well as excellent attenuation. Among its many features is an adjustable headband that maintains acoustical seal and gently conforms to the wearer’s head without undue pressure.


Superb noise attenuation guarantees intelligibility even in high noise environments, and close attention to ergonomics creates a fit that will surpass any other design in comfort and long-term wearability. Exceptionally clear voice signals are reproduced by magnetic or dynamic earphones, while additional comfort is added by foam or gel cups.


The Falcon can be customized to interface with any current communication system, made possible via plug-in design and your choice of earphones, switches, volume control, cords (straight or coiled), terminations, and preamps.


All Roanwell products can be customized to meet our customers’ requirements. Please call 718-401-0288 or use the form below to request a customized product quote.

Categories:

Headsets

Tags:

Aerospace, Military, Popular

ATTENUATION TABLE

• At 125 Hz: 14 dB

• At 250 Hz: 19 dB

• At 500 Hz: 26 dB

• At 1000 Hz: 26 dB

• At 2000 Hz: 28 dB

• At 4000 Hz: 30 dB

• At 8000 Hz: 28 dB


Noise Reduction Rating (NRR): 26 dB

TECHNICAL SPECIFICATIONS

Military Standards: Mil-H-83511, Mil-H-87819

FAA Approval: TSO-C57a Cat B, TSO-C58a Cat B

Replaces Part #: 11324CE, 12510G, H10-76

Operational Temperatures: -22°F to 140°F (-30°C to 60°C)

Microphone Type: Custom Variant, M-87, M101

Microphone Impedance: 150 Ω Standard or Per Customer Specification

Microphone Frequency Range: 200Hz to 6kHz (Standard)

Earphone Type: Custom Variant, H-143

Earphone Impedance: 19 Ω Standard or Per Customer Specification

Earphone Frequency Range: 200Hz to 6kHz (Standard)

Connector: U-174 Standard or Per Customer Specification
